The speed, freedom and the views offered by quiet roads are all included free with every Avant - and you love it.
AVANT CARBON FORK - The carbon layup and shaping of the Avant fork offers the best combination of elasticity, tire clearance and torsional stiffness.
HIGH POLISH - The new Avant receives the same level of design attention as Orbea´s carbon frames - the tubes are butted and hydroformed with smooth, polished welds to match the dramatic look of the monocoque frame.
ICR PLUS - Internal Cable Routing is carefully guided along the best path under the stem and through the head tube, with no rub or rattle, and is optimized for both traditional and electronic shifting systems.
Material | Aluminium |
Frame | Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5 ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system. |
Fork | Orbea carbon fork 2021, aluminum steerer, 1-1/8 head tube |
Rear derailleur | Shimano Claris RD-R2000-GS |
Front derailleur | Shimano Claris FD-R2000-F |
Shifters | Shimano Claris ST-R2000 |
Crankset | Shimano Claris R2000 34x50t |
Cassette | Shimano HG50 11-32t 8-Speed |
Handlebars | OC RP30-R Road Performance Riser, Reach 70, Drop 125, Rise 15, Flare 5º |
Stem | OC Road Performance RP21, -6º |
Seatpost | Alloy, 27.2mm, Setback 20 |
Tires | Vittoria Zafiro V Rigid bead 700x28c |
Wheels | Alloy, Tubeless, 700c, 19c, 28H |
Disc brakes | Jagwire RideRever Mechanical Disc |
Chain | KMC X8 |
Handlebar tape | Orbea Eva |
Headset | Acros Alloy 1-1/2 - Internal Cable Routing |
Saddle | Fizik Aliante R5 |
Drivetrain | Shimano Claris |
Number of gears | 2x8 |
