Materiál | Karbón |
Vidlica | Rock Shox Sid SL Select 29 , Charger RL, Solo Air 100mm |
Prehadzovačka | Shimano XT RD-M8100-SGS Shadow Design + 12sp |
Radenie | Shimano SLX 12sp |
Kľuky | FC-MT511-1, 32T, 52mm chainline, crank length 170mm-15 , 175mm-17/21 |
Kazeta | Shimano CS-M7100-12, 10-51T |
Riadidlá | Reparto Corse, double butted AL2014-T6, width 740mm, diam.31,8mm, backsweep 9° |
Predstavec | Reparto Corse, 3D forged AL7050-T6 w/forged alloy 4-bolt faceplate +/-7º, ext: 60mm-15'', 70mm-17 , 80mm-19 and 90mm-21 , 1.1/8 , diam.31.8mm |
Sedlovka | Reparto Corse Carbon SB0, lenght: 350mm-15'', 400mm-17/21 , diam.31.6mm, 0mm seatback, carbon UD fiber shaft with forged head |
Plášte | Kenda Booster Pro 29x2.20 |
Kolesá | Wtb KOM light i25 29 |
Brzdy | Shimano BR-M6100 |
Reťaz | Shimano CN-M7100, 12sp |
Stredové zloženie | Shimano BB-MT500-PA Pressfit 41x92mm |
Zadný náboj | Shimano FH-MT510-B |
Gripy | T-One T-GP43X |
Hlavové zloženie | Fsa Orbit C-40 |
Brzdové kotúče | Shimano RT-54, 180mm front & 160mm rear |
Sedlo | Fi'zi:k Taiga, S-alloy rails |
Tlmič | Sram Sid Luxe Select + RLR, 190/40mm, Debonair, w/eyelets 20mm x diam.8mm |
Sada radenia | Shimano XT |
Počet prevodov | 1x12 |
Zdvih odpruženia | 80-120 mm |
